Suction, discharge port diameter[mm (in)]
|
50 (1.97)
|
|
Discharge capacity [m3/h]
|
22
|
|
Total head lift [m (ft)]
|
26 (85.3)
|
|
Max suction head [m (ft)]
|
8 (26.25)
|
|
Rotation speed [rpm]
|
3600
|
|
Priming time [s/4m]
|
80
|
|
Overall dimension (LxWxH) [mm]
|
505x425x540
|
|
Dry weight [kg (lbs.)]
|
35 (77)
|
|
Engine model
|
SU170F
|
|
Rated power [KW (Hp)]
|
2.8 (3.8)
|
|
Rated rotation speed [rpm]
|
3600
|
|
Displacement [ml (cu.in)]
|
211 (12.88)
|
|
Starting system
|
Recoil starter/Electric starter
|
|
Fuel tank capacity [L (gal.)]
|
Small tank 2.5 (0.55)
|
|
Fuel consumption [g(ml)/KW.h]
|
285 (339.29)
|
